    LQ038Q5DR01 Sharp Lcd Screen , 30/60KHz Custom Lcd Display For Agilent N1913A


    LQ038Q5DR01 SHARP LCD SCREEN FOR AGILENT N1913A

    1,SHARP LQ038Q5DR01 Mechanical Features

    Panel Size :3.8 inch
    Dot Resolution :320(RGB)×240 (QVGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :106 PPI
    Aspect Ratio :15:10 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.082×0.2235 mm (H×V)
    Pixel Pitch :0.246×0.2235 mm (H×V)
    Weight :135g (Max.)
    Surface :Antiglare, Antireflection
    Active Area :78.72×53.64 mm (H×V)
    Outline Dimension :117.6×69.45 mm (H×V)
    Outline Depth :13.45 (Typ.) mm
    Holes & Brackets :Face mounting holes (4 pcs) on left, right slugs
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    2,SHARP LQ038Q5DR01 Optical Features

    Display Mode :TN, Normally White, Transmissive
    Brightness :450 cd/m² (Typ.)
    Contrast Ratio :100 : 1 (Min.) (Transmissive)
    Display Color :262K (6-bit)
    Response Time :30/50 (Typ.)(Tr/Td)
    Viewing Angle :65/65/40/65 (Typ.)(CR≥5) (L/R/U/D)
    Viewing Direction :6 o'clock
    White color Chromaticity :Wx:0.313; Wy:0.329

    3,SHARP LQ038Q5DR01 Electronics Feature

    Vertical Frequency :60Hz
    Reverse Scan :Yes (180°)

    4,SHARP LQ038Q5DR01 Backlight System

    Lamp Position :Edge light type (Bottom side)
    Lamp Type :CCFL
    Lamp Amount :1 pcs
    Lamp Life Time :20K(Min.) (Hours)
    Lamp Voltage :530±60V
    Lamp Current :5.5±0.5A
    Lamp Operating Frequency :30/60KHz (Min./Max.)
    Lamp Startup Voltage :1650/1700V (Typ.)(Ta=+25/-30℃)
    Interface Type :Connector
    Backlight InterfaceBrandModelPin PitchPinsAmountConfiguration
    JSTBHR-02(8.0)VS-1N8.0 mm2 pins1 pcsBLL-2PINS-HL
    Lamp Driver Board :No

    5,SHARP LQ038Q5DR01 Signal Interface

    Signal Category :TTL
    Signal Class :Parallel RGB (1 ch, 6-bit)
    Input Voltage for Panel :3.3V (Typ.)(VCC)
    Input Current for Panel :140/180mA (Typ./Max.)(ICC)
    Voltage for Display Signals :VIL≤0.3VCC; 0.7VCC≤VIH
    Interface Type :Connector
    Signal Interface :BrandModelPin PitchPinsAmountConfiguration
    JAEKX14-40K5D-VI-E1000E0.8 mm40 pins1 pcsDRGB-40P1C6B-200A

    6,SHARP LQ038Q5DR01 Packing Form

    Amount per Box :50 pcs
    Box Size :503×166×338 mm (L×W×H)
    Box Gross Weight :7.5 Kgs

    Model Number:LQ038Q5DR01


    Details Picture for LQ038Q5DR01 SHARP LCD SCREEN FOR AGILENT N1913A
